ISO application area | K15-K30 | ||
Material | Tungsten carbide,Tungsten Cobalt Alloy, | ||
Precision | 0.005-0.01mm | ||
Coating | AlTiN, TiAlN, TiAISI,TiSiN, TiN, DLC,Nano, Diamond | ||
Chemical Composition | Wc+other 89.5-90.5 Co 9.5-10.5 | ||
HRC | HRC45 HRC55 HRC58 HRC60 HRC65 | ||
Suitable For | cast iron, carbon steel, mould steel, stainless steel, titanium alloy, tool steel, and heat-treated steel |
3. Coating
Coating |
Color |
Coating Temperature |
Thickness (um) |
HV |
Application Temperature |
Friction coefficient |
TiAlN |
Purple-Gray | <600°C | 3-5 | 3300 | 800 °C | 0.3 |
AlTiN | Black | <600 °C | 3-5 | 3500 | 900 °C | 0.3 |
TiSiN | Copper | <600 °C | 3-5 | 3500 | 1500 °C | 0.4 |
NaNo | Blue | <600 °C | 3-5 | 3800 | 1200 °C | 0.4 |
CrN | Silver Gray | <480 °C | 2-2.5 | 2500 | 700 °C | 0.3 |
4. Packing
Laser print brand name on cutter shank, 1 pcs in a plastic tube, 10 pcs per group
5. Delivery time
Keep stock for regular types
Samples: 3 - 5 days
Regular orders: 7 - 10 days
