CNC Milling Cutter Solid Carbide T-Slot Milling Cutter For Metal
10 pcs
MOQ
USD 0.8~20/PCS
Price
CNC Milling Cutter Solid Carbide T-Slot Milling Cutter For Metal
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: ZhuZhou,China
Brand Name: GW Or OEM
Certification: ISO9001-2008-SGS
Model Number: HRC65 HRC55 HRC45
High Light:

Solid Carbide T-Slot Milling Cutter

,

CNC Carbide T-Slot Milling Cutter

,

HRC55 Carbide Ball Nose End Mills
Payment & Shipping Terms
Packaging Details: Standard Export Carton
Delivery Time: 7~15 working days
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 50000pcs/month
Specifications
Features: Good Wear Resistance, High Precision
Cutting Form: Flat, Ball Nose, Corner Radius, Roughing
Coating: Tisin, Tialn, Altin, Ticn, Blue Nano
Work Piece: HRC 65 HRC55 HRC45
Flutes Number: 2, 3, 4, 5, 6
Cutting Length: 1-50mm
Overall Length: 5-150mm
Certificates: ISO9001-2008-SGS
Shipment: FedEx,DHL,TNT
Delivery Time: 7~10days
Product Description

CNC Milling Cutter Solid Carbide T-Slot Milling Cutter For Metal

Product Overview
FEATURES AT A GLANCE
1. Products Description
Micro grain raw material
Grain size: 0.4-0.6μm
Co 10%, 12%
TRS >3600 N/mm2
Hardness HRA 91.8-92.5
Work piece HRC45-50 HRC55-60 HRC65 HRC68
Helix angle 30°-45 °
Diameter of cutting edge 0.2-0.9 mm; 1-20 mm
Diameter of rods 4-20 mm
Length 50-100 mm
Cutting Form Flat, Square, Ball nose, Corner Radius, Taper Flute, etc
Flutes No. 1-7

CNC Milling Cutter Solid Carbide T-Slot Milling Cutter For Metal 0
Carbide Grade
Technical Details of tungsten carbide rod
10U
Co:10% WC 89% rare element: 1% HRA: 90.5°Grain Size: 0.75um
12U
Co:12% WC 85% rare element: 3% HRA: 92.5°Grain Size: 0.4um
K40
Co:12% WC 84% rare element: 4% HRA: 93°Grain Size: 0.4um
K44
Co:12% WC 84% rare element: 4% HRA: 93.5°Grain Size: 0.4um
Carbide Grade
HRC of End mill
Materials to be cut
10U
HRC45-50
For cutting the materials under HRC35
12U
HRC55-58
For cutting the materials under HRC50
K40
HRC60-62
For cutting the materials under HRC55
K44
HRC65-70
For cutting the materials under HRC63
PRODUCT SPECIFICATIONS
Order No.
Flute dia (d)
Cutting length ( l )
Shank dia (D)
Overall length(L)
1.0×2.5×4D×50L
1.0
2.5
4
50
1.5×4×4D×50L
1.5
4
4
50
2.0×5×4D×50L
2.0
5
4
50
2.5×7×4D×50L
2.5
7
4
50
3.0×8×4D×50L
3.0
8
4
50
3.5×10×4D×50L
3.5
10
4
50
4.0×10×4D×50L
4
10
4
50
4.5×11×6D×50L
4.5
11
6
50
5.0×13×6D×50L
5.0
13
6
50
5.5×13×6D×50L
5.5
13
6
50
6.0×15×6D×50L
6.0
15
6
50
6.5×15×8D×60L
6.5
15
8
60
7.0×17×8D×60L
7.0
17
8
60
7.5×17×8D×60L
7.5
17
8
60
8.0×20×8D×60L
8.0
20
8
60
8.5×25×10D×75L
8.5
25
10
75
9.0×25×10D×75L
9.0
25
10
75
9.5×25×10D×75L
9.5
25
10
75
10.0×25×12D×75L
10.0
25
12
75
10.5×25×12D×75L
10.5
25
12
75
11.0×28×12D×75L
11.0
28
12
75
11.5×28×12D×75L
11.5
28
12
75
12.0×30×12D×75L
12.0
30
12
75
13.0×33×16D×100L
13.0
33
16
100
14.0×40×16D×100L
14.0
40
16
100
15.0×40×16D×100L
15.0
40
16
100
16.0×40×16D×100L
16.0
40
16
100
17.0×40×20D×100L
17.0
40
20
100
18.0×40×20D×100L
18.0
40
20
100
19.0×40×20D×100L
19.0
40
20
100
20.0×40×20D×100L
20.0
40
20
100
25.0×40×25D×100L
25.0
40
25
100
Product packaging
1. Application
Used for cutting Carbon steel, Tool steel, Mould steel, Stainless steel, Titanium alloy, Copper, Cast Iron and Aluminium, etc.

4. Packing
Brand Laser printed on cutter shank, 1 PCS in a plastic tube, 10 PCS a group

5. Delivery time
Keep stock for regular types
Samples: 3 - 5 days
Regular orders: 7 - 10 days

SIMILAR PRODUCTS
CNC Milling Cutter Solid Carbide T-Slot Milling Cutter For Metal 1
CNC Milling Cutter Solid Carbide T-Slot Milling Cutter For Metal 2
Our services
Our Services
More than 2000 products are available. Assembly line production, high standard and strict requirements.
OEM Services Offered
Customized Tools Offered
Free laser marking on tools and boxes Offered
Fast delivery time and Convenient Transportations.We have discount on shipping cost from our courier companies, such
asFEDEX,DHL,TNT, UPS etc.
Company Profile
Company Information

Zhuzhou Grewin Tungsten Carbide Tools Co., Ltd is located in hometown of Chinese carbide industry - Zhuzhou city. The company hasmore than 20 years' experience in manufacture, design and sale of various kinds of carbide products, main products include:Carbide end mills, carbide rods, indexable inserts, brazed inserts, wire drawing dies, forging dies, wood working tools, saw tips,mining buttons, etc
The company has passed ISO 9001: 2008 quality system, possesses advanced production equipments, complete testing instruments,strong R&D center and QC teams. With excellent quality, strong technical support, and good after sales service, Grewin Carbide brand products are sold to morethan 50 countries in the world, such as Europe, USA, south east Asia, Middle East, south America, etc.
The company is dedicated to " WE GROW, WE WIN". Grewin Carbide is growing up with the World's carbide technology, to meet thedemand of our customers from all over the world.
CNC Milling Cutter Solid Carbide T-Slot Milling Cutter For Metal 3
CNC Milling Cutter Solid Carbide T-Slot Milling Cutter For Metal 4
CNC Milling Cutter Solid Carbide T-Slot Milling Cutter For Metal 5
