2 Flute Solid Carbide End Mills with HRC55 Coating For Metal Milling
10pcs
MOQ
negotiable
Price
2 Flute Solid Carbide End Mills with HRC55 Coating For Metal Milling
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: Zhuzhou--Carbide City
Brand Name: Whitout Brand
Certification: ISO9001, SGS
Model Number: As your requirements
High Light:

square end mill cutter

,

square end drill bit

Payment & Shipping Terms
Packaging Details: 1PCS in a plastic tube, 10 PCS per group
Delivery Time: 15-25 work days
Payment Terms: T/T, PAYPAL, WESTERN UNION
Supply Ability: 50000pcs/Month
Specifications
Name: Solid Carbide End Mill
Diameter: 6-20mm, Customized
Length: 50-150mm, Customized
Helix Angel: 30° /35°/ 45°
Material: Tungsten Carbide
Coating: Altin, Tialn, OEM
Suitable For: Steel, Mould Steel, Stainless Steel
Product Description



2 Flutes Solid Carbide End Mills with HRC55 Coating For Metal Milling



1.Product Description



HRC choice: HRC38-45, HRC45-50, HRC55-58, HRC60-62, HRC65-70
Coating choice: AITiN, AICrSiN, AITiCrSIN, TiSiN, NACO-BLUE
Materials to be cut: original steel, cast iron, Aluminum, copper, graphite, plastics,
Titanium , alloy, harden steel, stainless steel, HSS etc



2.Introduction of carbide materials of the End mill



  AlTiN TiAlN TiSlN Nano
Hardness(HV) 3200 2800 3600 42(GPA)
Thickness(UM) 2.5-3 2.5-3 3 3
Oxidation Temp(°) 900 800 1000 1200
Friction Coefficient 0.3 0.3 0.45 0.4
Color Black Violet Copper

Blue



3. Code No.



Code No. Diamter
D
Cutting length
L
Total length
L
Shank
D
Flutes
Z
2GW1-01002050 1 3 50 4 2
2GW1-01504050 1.5 4 50 4 2
2GW1-02050500 2 5 50 4 2
2GW1-02507050 2.5 7 50 4 2
2GW1-03008050 3 8 50 4 2
2GW1-04010050 4 10 50 4 2
2GW1-04015075 4 15 75 4 2
2GW1-04020100 4 20 100 4 2
2GW1-05012050 5 13 50 6 2
2GW1-06015050 6 15 50 6 2
2GW1-06020075 6 20 75 6 2
2GW1-06020100 6 30 100 6 2
2GW1-06020060 8 20 60 8 2
2GW1-08025075 8 25 75 8 2
2GW1-08025100 8 35 100 8 2
2GW1-010025075 10 25 75 10 2
2GW1-010040100 10 40 100 10 2
2GW1-012020075 12 30 75 12 2
2GW1-012040100 12 40 100 12 2
2GW1-014020080 14 30 80 14 2
2GW1-014100100 14 40 100 14 2
2GW1-016040100 16 40 100 16 2
2GW1-018040100 18 40 100 18 2
2GW1-020040100 20 40 100 20 2
2GW1-06040150 6 40 150 6 2
2GW1-08050150 8 50 150 8 2
2GW1-010050150 10 50 150 10 2
2GW1-012050150 12 50 150 12 2
2GW1-014060150 14 60 150 14 2
2GW1-016060150 16 60 150 16 2
2GW1-018060150 18 60 150 18 2
2GW1-020060150 20 60 150 20 2
