Black/Silver/Blue Color Ball Nose End Mills Carbide Solid Milling Tools
1. . Common Problem
We are not Professional manufacturer, but we have more than 20 years experience with excellent manufacturer cooperation in this field.
You can arrange transportation. We can provide samples.
(3) Do you make label?
Yes, we do. We have laser machine, can laser your logo and sizes on the body of milling cutter, also can print labels.
(4) How about the delivery time?
According to the sizes and quantity, delivery time is different. Usually be 3~5 days. We can tell you exact inventory state if you need.
(5) Can you produce carbide Special Tool ?
Yes We can. We can special tool according your drawing and sample.
2.Products Description
Micro grain raw material
Grain size: 0.4-0.6μm
Co 10%, 12%
TRS >3600 N/mm2
Hardness HRA 91.8-92.5
Work piece HRC45-50 HRC55-60 HRC65 HRC70
Helix angle 30°-45 °
Diameter of cutting edge 0.2-0.9 mm; 1-20 mm
Diameter of rods 4-20 mm
Length 50-100 mm
Cutting Form Flat, Square, Ball nose, Corner Radius, Taper Flute, etc
Flutes No. 1-7
| HRC45 | HRC55 | HRC60 | HRC65 |
| Grain Size: 0.6um Co: 10 % Flexural strength: 3350N/mm2 |
Grain Size: 0.6um Co: 10 % Flexural strength: 4000N/mm2 |
Grain Size: 0.5um Co: 12 % Flexural strength: 4300N/mm2 |
Grain Size: 0.4um Co: 12.5 % Flexural strength: 4300N/mm2 |
3. Excellent Raw Material and Coating Type
| TYPE | Material | MG grain size | CO | Flexural strength |
| HRC45 | YG10X | 0.7um | 10% | 3320N/mm2 |
| HRC55 | YL10.2 &WF25 | 0.6um | 10% | 4000N/mm2 |
| HRC60 | K44 &K40 | 0.5um | 12% | 4300N/mm2 |
| HRC65 | H10F | 0.5um | 10% | 4300N/mm2 |
| Coating Type | Hardness(HV) | Thickness(UM) | Oxidation Temp.(℃) | Color | Friction Coefficient |
| AlTin | 3200 | 2.5-3 | 900 | Black | 0.3 |
| Tialn | 2800 | 2.5-3 | 800 | Violet | 0.3 |
| TiSin | 3600 | 3 | 1000 | Copper | 0.45 |
| Naco | 42(GPA) | 3 | 1200 | Bule | 0.4 |
4. Payment
T/T, Western Union, Paypal (Choose your convenient way)
5. Shipment
FedEx, TNT, DHL, UPS, EMS, etc.
The port is Beijing, Shanghai, Guangzhou, Shenzhen, any port in China. (choose your convenient way)
6. Delivery time
Keep stock for regular types
Samples: 3 - 5 days
Regular orders: 7 - 10 days
7.Our Services
More than 2000 products are available. Assembly line production, high standard and strict requirements.
OEM Services Offered
Customized Tools Offered
Free laser marking on tools and boxes Offered
Fast delivery time and Convenient Transportations. We have discount on shipping cost from our courier companies, such as FedEx, DHL, TNT, UPS etc.
Warmly Welcome your contact and inquiry here!
