High Speed Carbide Ball Nose End Mills CNC Machines Cutting HRC45
10pcs
MOQ
negotiable
Price
High Speed Carbide Ball Nose End Mills CNC Machines Cutting HRC45
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: Zhuzhou--Carbide City
Brand Name: Whitout Brand
Certification: ISO9001, SGS
Model Number: As your requirements
High Light:

HRC45 Carbide Ball Nose End Mills

,

OEM Carbide Ball Nose End Mills

,

CNC high speed carbide end mills

Payment & Shipping Terms
Packaging Details: 1PCS in a plastic tube, 10 PCS per group
Delivery Time: 15-25 work days
Payment Terms: T/T, PAYPAL, WESTERN UNION
Supply Ability: 50000pcs/Month
Specifications
Workpiece: Steel, Cast Iron, Stainless Steel, Aluminum Etc
Hardness: HRC45,50,55,65 Etc
Samples: Free
Characteristics: High Precision, High Hardness Etc
NO Of Flutes: 1,2,3,4,5,6 Etc
OEM: Avaiable
Helix Angle: 30,35,45
Cutting Form: Flat, Ball Nose ,corner Radius, Aluminum Etc
Product Description







High Speed Solid Carbide Ball Nose End Mills Applying On CNC Machines Cutting




1. Normal Sizes



Order No. Flute dia (d) Cutting length ( l ) Shank dia (D) Overall length(L)
1.0×2.5×4D×50L 1.0 2.5 4 50
1.5×4×4D×50L 1.5 4 4 50
2.0×5×4D×50L 2.0 5 4 50
2.5×7×4D×50L 2.5 7 4 50
3.0×8×4D×50L 3.0 8 4 50
3.5×10×4D×50L 3.5 10 4 50
4.0×10×4D×50L 4 10 4 50
4.5×11×6D×50L 4.5 11 6 50
5.0×13×6D×50L 5.0 13 6 50
5.5×13×6D×50L 5.5 13 6 50
6.0×15×6D×50L 6.0 15 6 50
6.5×15×8D×60L 6.5 15 8 60
7.0×17×8D×60L 7.0 17 8 60
7.5×17×8D×60L 7.5 17 8 60
8.0×20×8D×60L 8.0 20 8 60
8.5×25×10D×75L 8.5 25 10 75
9.0×25×10D×75L 9.0 25 10 75
9.5×25×10D×75L 9.5 25 10 75
10.0×25×12D×75L 10.0 25 12 75
10.5×25×12D×75L 10.5 25 12 75
11.0×28×12D×75L 11.0 28 12 75
11.5×28×12D×75L 11.5 28 12 75
12.0×30×12D×75L 12.0 30 12 75
13.0×33×16D×100L 13.0 33 16 100
14.0×40×16D×100L 14.0 40 16 100
15.0×40×16D×100L 15.0 40 16 100
16.0×40×16D×100L 16.0 40 16 100
17.0×40×20D×100L 17.0 40 20 100
18.0×40×20D×100L 18.0 40 20 100
19.0×40×20D×100L 19.0 40 20 100
20.0×40×20D×100L 20.0 40 20 100
25.0×40×25D×100L 25.0 40 25 100



2.. Why you choose us Grewin Tungsten Carbide?


Zhuzhou Grewin Tungsten Carbide Tools Co., Ltd is located in hometown of Chinese carbide industry - Zhuzhou city. The company has more than 20 years' experience in manufacture, design and sale of various kinds of carbide products, main products include: Carbide end mills, carbide rods, indexable inserts, brazed inserts, wire drawing dies, forging dies, wood working tools, saw tips, mining buttons, etc

The company has passed ISO 9001: 2008 quality system, possesses advanced production equipments, complete testing instruments, strong R&D center and QC teams.
With excellent quality, strong technical support, and good after sales service, Grewin Carbide brand products are sold to more than 50 countries in the world, such as Europe, USA, south east Asia, Middle East, south America, etc.
The company is dedicated to " WE GROW, WE WIN". Grewin Carbide is growing up with the World's carbide technology, to meet the demand of our customers from all over the world.



3. Strict quality checking

(1) Check each piece. Guarantee the tolerance -0.02mm
(2) Exact helix angle and finished surface
(3) Goods pass SGS and ISO9001

4.Machining Operation of Tungsten Carbide Solid Endmill cutter bits



Ball nose end mills profile machining profile machining slot machining deep slot machining
R end mills side machining slot machining profile machining
Flattened end mills side machining shoulder machining straight slot machining deep slot machining


5. Application and usage

(1) Suitable for Copper, Cast Iron, Carbon steel, Tool steel, Mould steel, Die steel, Stainless steel, Plastic, Arcylic, etc.
(2) Applicated for aerospace, transportation, Medical equipment, Military manufacturing, Mould development, Apparatus and instrument, etc.

6. Payment

T/T, Western Union, Paypal (Choose your convenient way)



7.Our Services
More than 2000 products are available. Assembly line production, high standard and strict requirements.
OEM Services Offered
Customized Tools Offered
Free laser marking on tools and boxes Offered
Fast delivery time and Convenient Transportations. We have discount on shipping cost from our courier companies, such as FedEx, DHL, TNT, UPS etc.



High Speed Carbide Ball Nose End Mills CNC Machines Cutting HRC45 0





High Speed Carbide Ball Nose End Mills CNC Machines Cutting HRC45 1









Alice is waiting for your early contact and inquiries here!

E-mai: alice-gwcarbide@vip.163.com

Whatsapp: 86-18675856108
