2 Flutes Solid Carbide End Mill Flat And Square Micro Diameter HRC55-58
10pcs
MOQ
negotiable
Price
2 Flutes Solid Carbide End Mill Flat And Square Micro Diameter HRC55-58
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: Zhuzhou--Carbide City
Brand Name: Whitout Brand
Certification: ISO9001, SGS
Model Number: As your requirements
High Light:

indexable cutting tools

,

indexable carbide end mill

Payment & Shipping Terms
Packaging Details: 1PCS in a plastic tube, 10 PCS per group
Delivery Time: 15-25 work days
Payment Terms: T/T, PAYPAL, WESTERN UNION
Supply Ability: 50000pcs/Month
Specifications
Material: Carbide
HRC: HRC55-58
Coatting Choice: TiAIN
Workpiece Material: Original Steel , Cast Iron , Aluminum , Copper , Plastic , SS , HSS , Etc.
End Mill Flute Diameter: 0.1-4.9
Cutting Form: Flat , Ball Nose
Product Description

2 Flutes Flat And Square Micro Diameter Solid Carbide End Mill



1. Products Description

Micro grain raw material
Grain size: 0.4-0.6μm
Co 10%, 12%
TRS >3600 N/mm2
Hardness HRA 91.8-92.5
Work piece HRC45-50 HRC55-60 HRC65 HRC68
Helix angle 30°-45 °
Diameter of cutting edge 0.1-0.9 mm; 1-20 mm
Cutting Form Flat, Square, Ball nose, Corner Radius, Taper Flute, etc
Flutes No. 1-6

HRC45 HRC55 HRC60 HRC65
Grain Size:0.6um
Co:10 %
Flexural strength:3350N/mm2
Grain Size:0.6um
Co:10 %
Flexural strength:4000N/mm2
Grain Size:0.5um
Co:12 %
Flexural strength:4300N/mm2
Grain Size:0.4um
Co:12.5 %
Flexural strength:4300N/mm2



2. Application

Used for cutting Carbon steel, Tool steel, Mould steel, Stainless steel, Titanium alloy, Copper, Cast Iron and Aluminium, etc.

Grinding equipment: WALTER, ANCA, ROLLOMATIC
Testing equipment: ZOLLER

3. Coating


Coating

Color

Coating Temperature

Thickness (um)

HV

Application Temperature

Friction coefficient

TiAlN
Purple-Gray <600°C 3-5 3300 800 °C 0.3
AiTiN Black <600 °C 3-5 3500 900 °C 0.3
TiXco Copper <600 °C 3-5 3500 1500 °C 0.4
NaNo Blue <600 °C 3-5 3800 1200 °C 0.4
AiCrN Silver Gray <480 °C 2-2.5 2500 700 °C 0.3


4. Payment
T/T, Western Union, Paypal (Choose your convenient way)

5. Shipment
FEDEX, TNT,DHL, UPS, EMS,etc.
The port is Beijing,Shanghai ,Guangzhou ,Shenzhen,any port in China. (choose your convenient way)

6. Packing

Laser print brand name on cutter shank, 1 pcs in a plastic tube, 10 pcs per group

7. Delivery time

Keep stock for regular types
Samples: 3 - 5 days
Regular orders: 7 - 10 days
