Solid Straight Carbide Ball Nose End Mill Cutter CNC Machines Cutting Usage
10pcs
MOQ
negotiable
Price
Solid Straight Carbide Ball Nose End Mill Cutter CNC Machines Cutting Usage
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: Zhuzhou--Carbide City
Brand Name: Whitout Brand
Certification: ISO9001, SGS
Model Number: As your requirements
High Light:

indexable ball nose end mill

,

ball nose end mill cutter

Payment & Shipping Terms
Packaging Details: 1PCS in a plastic tube, 10 PCS per group
Delivery Time: 15-25 work days
Payment Terms: T/T, PAYPAL, WESTERN UNION
Supply Ability: 50000pcs/Month
Specifications
Cutting Style: Flat, Ball Nose ,corner Radius, Aluminum Etc
Workpiece: Steel, Cast Iron, Stainless Steel, Aluminum Etc
Hardness: HRC45,50,55,65 Etc
Diameter: D1-D25
Samples: Free
Characteristics: High Precision, High Hardness Etc
NO Of Flutes: 1,2,3,4,5,6 Etc
OEM: Avaiable
Product Description

Solid Straight Carbide Ball Nose End Mill Cutter CNC Machines Cutting Usage

1. Why you choose us Grewin Tungsten Carbide?
Zhuzhou Grewin Tungsten Carbide Tools Co., Ltd is located in hometown of Chinese carbide industry - Zhuzhou city. The company has more than 20 years' experience in manufacture, design and sale of various kinds of carbide products, main products include: Carbide end mills, carbide rods, indexable inserts, brazed inserts, wire drawing dies, forging dies, wood working tools, saw tips, mining buttons, etc
The company has passed ISO 9001: 2008 quality system, possesses advanced production equipments, complete testing instruments, strong R&D center and QC teams.
With excellent quality, strong technical support, and good after sales service, Grewin Carbide brand products are sold to more than 50 countries in the world, such as Europe, USA, south east Asia, Middle East, south America, etc.
The company is dedicated to " WE GROW, WE WIN". Grewin Carbide is growing up with the World's carbide technology, to meet the demand of our customers from all over the world.
2. Normal Sizes


Order No.Flute dia (d)Cutting length ( l )Shank dia (D)Overall length(L)
1.0×2.5×4D×50L1.02.5450
1.5×4×4D×50L1.54450
2.0×5×4D×50L2.05450
2.5×7×4D×50L2.57450
3.0×8×4D×50L3.08450
3.5×10×4D×50L3.510450
4.0×10×4D×50L410450
4.5×11×6D×50L4.511650
5.0×13×6D×50L5.013650
5.5×13×6D×50L5.513650
6.0×15×6D×50L6.015650
6.5×15×8D×60L6.515860
7.0×17×8D×60L7.017860
7.5×17×8D×60L7.517860
8.0×20×8D×60L8.020860
8.5×25×10D×75L8.5251075
9.0×25×10D×75L9.0251075
9.5×25×10D×75L9.5251075
10.0×25×12D×75L10.0251275
10.5×25×12D×75L10.5251275
11.0×28×12D×75L11.0281275
11.5×28×12D×75L11.5281275
12.0×30×12D×75L12.0301275
13.0×33×16D×100L13.03316100
14.0×40×16D×100L14.04016100
15.0×40×16D×100L15.04016100
16.0×40×16D×100L16.04016100
17.0×40×20D×100L17.04020100
18.0×40×20D×100L18.04020100
19.0×40×20D×100L19.04020100
20.0×40×20D×100L20.04020100
25.0×40×25D×100L25.04025100


3. Strict quality checking
(1) Check each piece. Guarantee the tolerance -0.02mm
(2) Exact helix angle and finished surface
(3) Goods pass SGS and ISO9001
4.Machining Operation of Tungsten Carbide Solid Endmill cutter bits


Ball nose end millsprofile machiningprofile machiningslot machiningdeep slot machining
R end millsside machiningslot machiningprofile machining
Flattened end millsside machiningshoulder machiningstraight slot machiningdeep slot machining


5. Application and usage
(1) Suitable for Copper, Cast Iron, Carbon steel, Tool steel, Mould steel, Die steel, Stainless steel, Plastic, Arcylic, etc.
(2) Applicated for aerospace, transportation, Medical equipment, Military manufacturing, Mould development, Apparatus and instrument, etc.
6. Payment
T/T, Western Union, Paypal (Choose your convenient way)
7. Shipment
FedEx, TNT, DHL, UPS, EMS, etc.
The port is Beijing, Shanghai, Guangzhou, Shenzhen, any port in China. (choose your convenient way)
8..Our Services
More than 2000 products are available. Assembly line production, high standard and strict requirements.
OEM Services Offered
Customized Tools Offered
Free laser marking on tools and boxes Offered
Fast delivery time and Convenient Transportations. We have discount on shipping cost from our courier companies, such as FedEx, DHL, TNT, UPS etc.
