Home /Products/Square End Mills/Four Flute Square End Mills High Toughness With High Speed Steel Material

Four Flute Square End Mills High Toughness With High Speed Steel Material

2pc
MOQ
4—200 USD
Price
Four Flute Square End Mills High Toughness With High Speed Steel Material
Features Gallery Product Description Chat Now
Features
Specifications
Highlight:

Four Flute Square End Mills

,

High Toughness Square End Mills

,

Four Flute square end tool
Basic Infomation
Place of Origin: China
Brand Name: ARNOLD
Certification: ISO9001:2000
Model Number: AHSEF 4-flute End Mills
Payment & Shipping Terms
Delivery Time: 7-10 days
Supply Ability: 1000000 Piece/Pieces per Month
Product Description
Four Flute Square End Mills Boosts Cutting Efficiency by 30%
Product Description
Material Features: Adopt extremely fine ultramicron matrix with great toughness and hardness
Super-Y Coating Features:
  • High red hardness increases cutting speed
  • High stability with strong adhesion on the coating surface
  • High coating hardness improves tool life
  • High temperature resistance enables high-speed machining
  • Suitable for dry cutting or micro-lubrication cutting
Technical Parameters
极
Order Code Designation Cutting Diameter (ds) Cutting Length (Ic) Neck Radius (R) Shank Angle (Y1°) Overall Length (lo) Shank Diameter (ds) Graph Inventory
AHSEF40100450 D1x3xL50xSD4 1 3 4 12 50 4 A ●
AHSEF40100650 D1x3xL50xSD6 1 3 4 12 50 6 A ●
AHSEF40150450 D1.5x4xL50xSD4 1.5 4   11 50 4 A ●
AHSEF40150650 D1.5x4xL50xSD6 1.5 4   11 50 6 A ●
AHSEF40200450 D2x5xL50xSD4 2 5   11 50 4 A *
AHSEF40200650 D2x5xL50xSD6 2 5   11 50 6 A *
AHSEF40250450 D2.5x6.5xL50xSD4 2.5 6.5   11 50 4 A ●
AHSEF40250650 D2.5×6.5xL50xSD6 2.5 6.5   11 50 6 A *
AHSEF40300450 D3x7.5xL50xSD4 3 7.5   11 50 4 A *
AHSEF40300650 D3x7.5xL50xSD6 3 7.5   11 50 6 A
AHSEF40300660 D3x7.5xL60xSD6 3 7.5   11 60 6 A ●
AHSEF40300675 D3x7.5xL75xSD6 3 7.5   11 75 6 A
AHSEF40400450 D4x10xL50xSD4 4 10   - 50 4 B *
AHSEF40400460 D4x10xL60xSD4 4 10   - 60 4 B
AHSEF40400475 D4x10xL75xSD4 4 10   - 75 4 B
AHSEF40400650 D4x10xL50xSD6 4 10   11 50 6 A ●
AHSEF40400660 D4x10xL60xSD6 4 10   11 60 6 A
AHSEF40400675 D4x10xL75xSD6 4 10   11 75 6 A ●
AHSEF40500650 D5x12.5xL50xSD6 5 12.5   11 50 6 A *
AHSEF40500675 D5x12.5xL75xSD6 5 12.5   11 75 6 A ●
AHSEF40600650 D6x15xL50xSD6 6 15   - 50 6 B ●
AHSEF40600660 D6x15xL60xSD6 6 15   - 60 6 B
AHSEF40600675 D6x15xL75xSD6 6 15   - 75 6 B ●
AHSEF406006100 D6x15xL100xSD6 6 15   - 100 6 B ●
AHSEF40800860 D8x20xL60xSD8 8 20   - 60 8 B
AHSEF40800875 D8x20xL75xSD8 8 20   - 75 8 B ●
AHSEF408008100 D8x20xL100xSD8 8 20   - 100 8 B ●
AHSEF41001075 D10x25xL75xSD10 10 25   - 75 10 B ●
AHSEF410010100 D10x25xL100xSD10 10 25   - 100 10 B *
AHSEF41201275 D12x30xL75xSD12 12 30   - 75 12 B ●
AHSEF412012100 D12x30xL100xSD12 12 30   - 100 12 B *
AHSEF41401475 D14×35xL75xSD14 14 35   - 75 14 B *
AHSEF414014100 D14x35×L100xSD14 14 35   - 100 14 B *
AHSEF416016100 D16x40xL100xSD16 16 40   - 100 16 B ●
AHSEF416016150 D16x40xL150xSD16 16 40   - 150 16 B ●
AHSEF420020100 D20x50xL100xSD20 20 50   - 100 20 B ●
AHSEF420020150 D20x50xL150xSD20 20 50   - 150 20 B ●
Applications
Suitable for machining hardened steel (HRC50-65)
Ideal for materials including SKD61, S136H, SKD11, etc.
Excellent for machining high-alloy materials
