Product Description:
special blade design, combined with advanced polishing
passivation technology, effectively prevent vibration and solve the problem of sticking chips;
High-performance aluminum knife can achieve ultra-high metal removal rate and higher requirements for appearance effects.
Features:
Key Features of Square End Mills:
Flat Cutting End: Produces flat surfaces and sharp 90° corners.
Precision Milling: Ideal for accurate slotting, contouring, and pocketing.
Versatile Flute Options: Available in 2, 3, 4 or more flutes for different cutting conditions.
Material Compatibility: Suitable for cutting steel, aluminum, stainless steel, plastic, and composites.
High Surface Finish: Provides smooth cutting and clean edges.
Various Coatings Available: TiN, TiAlN, AlTiN, etc., to increase tool life and performance.
Solid Construction: Typically made from carbide or high-speed steel (HSS) for durability.
CNC Machine Ready: Designed for use in high-speed CNC machining operations.
Cost-Effective: A reliable choice for general-purpose milling tasks.
Technical Parameters:
| Type No. |
Diameter |
Flute length |
Overall length |
Shank Dia |
Flutes |
| AES0303A |
D3 |
8 |
L50 |
4 |
3 |
| AES0303 |
D3 |
8 |
L50 |
6 |
3 |
| AES0403A |
D4 |
12 |
L50 |
4 |
3 |
| AES0403 |
D4 |
12 |
L50 |
6 |
3 |
| AES0503 |
D5 |
15 |
L50 |
6 |
3 |
| AES0603 |
D6 |
18 |
L50 |
6 |
3 |
| AES0803 |
D8 |
20 |
L60 |
8 |
3 |
| AES1003 |
D10 |
25 |
L75 |
10 |
3 |
| AES1203 |
D12 |
30 |
L75 |
12 |
3 |
| AES1603 |
D16 |
45 |
L100 |
16 |
3 |
| AES2003 |
D20 |
45 |
L100 |
20 |
3 |
|
Applications:
Applications of Square End Mills:
Slotting – Cutting straight slots with sharp edges in a variety of materials.
Profiling – Milling along part contours with precision.
Pocketing – Creating flat-bottomed cavities or recessed areas.
Side Milling – Machining the sides of workpieces with high accuracy.
Face Milling – Producing flat surfaces on the workpiece.
Sharp Corner Machining – Ideal for components that require 90° internal corners.
Mold and Die Making – Used in tool & die production for precise edge definition.
Prototype Manufacturing – Common in rapid prototyping and custom part fabrication.
CNC Machining Centers – Widely used in automated production environments.
Machining of Metals and Plastics – Effective on materials like steel, aluminum, brass, and thermoplastics.
FAQ:
Q: What is the brand name of the Square End Mills product?
A: The brand name of the Square End Mills product is ARNOLD.
Q: Where is the Square End Mills product manufactured?
A: The Square End Mills product is manufactured in China.
Q: What certification does the Square End Mills product have?
A: The Square End Mills product is certified with ISO9001:2000.
Q: What is the minimum order quantity for the Square End Mills product?
A: The minimum order quantity for the Square End Mills product is 2 pieces.
Q: What are the packaging details for the Square End Mills product?
A: The Square End Mills product comes with standard packaging.
