Product Description:
Exchangeable Tip Drilling is an innovative drilling technique that employs a tool body that can be reused, featuring cutting tips that are replaceable. This method provides cost-efficiency, reliable performance, and minimized downtime in machining operations that involve high production volumes.
The key advantage of Exchangeable Tip Drilling lies in the ability to simply replace the worn-out cutting tips instead of discarding the entire tool, leading to significant cost savings over time. The consistent performance of this drilling approach ensures precision and quality in the machining process, contributing to improved overall efficiency.
Features:
Key Advantages of Exchangeable Tip Drilling:
Reduced Tooling Costs: Only the tip needs to be replaced, minimizing the cost per hole compared to solid drills.
Minimized Downtime: Quick and easy tip changes reduce machine setup time and increase productivity.
Consistent Hole Quality: Precision-manufactured tips ensure high repeatability in hole diameter, roundness, and surface finish.
Extended Tool Body Life: The durable tool holder can be reused for many cycles, reducing waste and total tool replacement frequency.
High Flexibility: A single tool body can accommodate different tip geometries and sizes for various materials and applications.
Lower Inventory Requirements: Fewer complete tools need to be stocked; just a range of tips and a few tool bodies are sufficient.
Environmentally Friendly: Less material waste compared to replacing entire drills supports sustainable manufacturing practices.
Technical Parameters:
| |
AHNO
|
竞争对手
|
|
钻尖Diameter
|
EP197-P-1950
|
D19.5钻尖
|
|
直径Diameter
|
19.50mm
|
19.50mm
|
|
材质Material Grade
|
P20
|
|
|
Vc(线速度m/min)
|
85.7
|
85.7
|
|
S(转速r/min)
|
1400
|
1400
|
|
F(进给mm/min)
|
316
|
316
|
|
f(每齿进给mm/r)
|
0.22
|
0.22
|
|
孔深Drilling Depth
|
45
|
45
|
|
寿命Tool Life
|
1100孔
|
750孔
|
|
Order Code
|
Cutting
Edges No.
|
Dc
|
L2
|
L1
|
Seat Size
|
Matching Drill Body
|
|
EP197-P-1700
EP197-P-1724
EP197-P-1740
EP197-P-1750
EP197-P-1760
EP197-P-1786
|
2
2
2
2
2
2
|
17.00 17.24 17.40 17.50 17.60
17.86
|
7.0
7.0
7.0
7.0
7.0
7.0
|
12.6
12.6
12.6
12.6
12.6
12.6
|
1
1
1
1
1
1
|
EP-G8810.-17-B20
|
|
EP197-P-1800
|
2
|
18.00
|
7.0
|
12.6
|
1
|
EP-G8810.-18-B20
|
|
EP197-P-1801
EP197-P-1826
EP197-P-1850
EP197-P-1875
EP197-P-1890
|
2
2
2
2
2
|
18.01 18.26 18.50 18.75
18.90
|
7.5
7.5
7.5
7.5
7.5
|
13.6
13.6
13.6
13.6
13.6
|
2
2
2
2
2
|
EP-G8810.-181-B25
|
|
EP197-P-1900
EP197-P-1927
EP197-P-1930
EP197-P-1933
EP197-P-1950
EP197-P-1990
|
2
2
2
2
2
2
|
19.00 19.27 19.30 19.33 19.50
19.90
|
7.5
7.5
7.5
7.5
7.5
7.5
|
13.6
13.6
13.6
13.6
13.6
13.6
|
2
2
2
2
|
EP-G8810.-19-B25
|
|
EP197-P-2000
EP197-P-2010
EP197-P-2060
EP197-P-2080
|
2
2
2
2
|
20.00 20.10 20.60
20.80
|
8.5
8.5
8.5
8.5
|
14.6
14.6
14.6
14.6
|
3
3
3
3
|
EP-G8810.-20-B25
|
|
EP197-P-2100
EP197-P-2143
EP197-P-2150
EP197-P-2190
|
2
2
2
2
|
21.00 21.43 21.50
21.90
|
8.5
8.5
8.5
8.5
|
14.6
14.6
14.6
14.6
|
3
3
3
3
|
EP-G8810.-21-B25
|
|
EP197-P-2200
|
2
|
22.00
|
8.5
|
14.6
|
3
|
EP-G8810.-22-B25
|
|
EP197-P-2201
EP197-P-2290
|
2
2
|
22.01
22.90
|
9.5
9.5
|
15.6
15.6
|
4
4
|
EP-G8810.-221-B25
|
|
EP197-P-2300
EP197-P-2342
EP197-P-2350
EP197-P-2390
|
2
2
2
2
|
23.00 23.42 23.50
23.90
|
9.5
9.5
9.5
9.5
|
15.6
15.6
15.6
15.6
|
4
4
4
4
|
EP-G8810.-23-B25
|
|
EP197-P-2400
|
2
2
2
2
2
|
24.00
|
9.5
|
15.6
|
4
|
EP-G8810.-24-B25
|
|
EP197-P-2401
EP197-P-2450
EP197-P-2461
EP197-P-2490
|
24.01 24.50 24.61
24.90
|
10.0
10.0
10.0
10.0
|
16.6
16.6
16.6
16.6
|
5
5
5
|
EP-G8810.-241-B32
|
|
EP197-P-2500
EP197-P-2527
EP197-P-2533
EP197-P-2540
EP197-P-2567
|
2
2
2
2
2
|
25.00 25.27 25.33 25.40
25.67
|
10.0
10.0
10.0
10.0
10.0
|
16.6
16.6
16.6
16.6
16.6
|
5
5
5
5
5
|
EP-G8810.-25-B32
|
|
EP197-P-2600
EP197-P-2601
EP197-P-2619
EP197-P-2650
EP197-P-2690
|
2
|
26.00
|
10.0
|
16.6
|
5
|
EP-G8810.-26-B32
|
|
2
2
2
2
|
26.01 26.19 26.50
26.90
|
11.0
11.0
11.0
11.0
|
17.6
17.6
17.6
17.6
|
6
6
6
6
|
EP-G8810.-261-B32
|
Applications:
Applications of Exchangeable Tip Drilling
Automotive Industry
- Engine blocks, cylinder heads, transmission components
- High-volume, high-speed drilling of cast iron, steel, and aluminum alloys
Aerospace Industry
- Aircraft structural components, landing gear parts
- Drilling of high-strength alloys like titanium and Inconel
General Machining
- CNC machining centers, multi-spindle machines
- Efficient holemaking in various mechanical parts and tools
Oil & Gas / Energy Sector
- Valve bodies, pumps, and pipeline components
- Deep hole drilling in tough materials like stainless steels
Heavy Equipment / Construction Machinery
- Large frame components, gear housings, hydraulic systems
- Durable drilling performance under high torque loads
Die & Mold Industry
- Pre-drilling for EDM or cooling channels
- Precision holemaking in hardened tool steels
Metal Fabrication
- Structural steel fabrication, tubular assemblies
- Fast and reliable drilling in beams, plates, and hollow sections
