Name: HRC45 Cemented Carbide Square End Mill For CNC Machines Milling
Brand: Whitout Brand
SKU: As your requirements
Price: 1.00 USD
Availability: InStock
Rating: 4.8 (159 reviews)
ISBN: 11130697

Features Gallery Product Description Request A Quote

Features

Basic Infomation

Place of Origin: Zhuzhou--Carbide City

Brand Name: Whitout Brand

Certification: ISO9001, SGS

Model Number: As your requirements

High Light:

square end drill bit

square end mill cutter

Payment & Shipping Terms

Packaging Details: 1PCS in a plastic tube, 10 PCS per group

Delivery Time: 15-25 work days

Payment Terms: T/T, PAYPAL, WESTERN UNION

Supply Ability: 50000pcs/Month

Specifications

Materials: 100% Virgin Tungsten Carbide

Grade: HRC45,HRC50,HRC60 Etc

Coating: ALTIN,TIALN,TISIN,NANO Etc

Helix Angle: 30,35,45, Etc

Flutes Number: 2,3,4,6etc

Shape Of Cuttiing Edge: Flat,ballnose, Corner Radius Etc

Shank Type: Straight Shank, Groove Shank Etc

OEM: Accepted

Gallery

Product Description

1. Products Description

Grain size: 0.4-0.6um
Co : 10%, 12%
TRS : >3600 N/mm2
Hardness: HRA 91.8-92.5
Work piece: HRC45-50 HRC55-58 HRC60-62 HRC65-60
Helix angle: 30°-60°
Dia of cutting edge : 0.2-0.9 mm; 1-20 mm
Diameter of rods: 4-20 mm
Length: 50-100 mm
Cutting Form: Flat, Square, Ball nose, Corner Radius, Taper Flute, etc
Flutes No. : 1-7 flutes

HRC45	HRC55	HRC60	HRC65
Grain Size:0.6um Co:10 % Flexural strength:3350N/mm2	Grain Size:0.6um Co:10 % Flexural strength:4000N/mm2	Grain Size:0.5um Co:12 % Flexural strength:4300N/mm2	Grain Size:0.4um Co:12.5 % Flexural strength:4300N/mm2

2.Application

Used for cutting: Carbon steel, Tool steel, Mould steel, Stainless steel, Titanium alloy, Copper, Cast Iron and Aluminium, etc.
Grinding equipment: , ANCA, ROLLOMATIC etc
Testing equipment: ZOLLER

3. Coating

Coating	Color	Coating Temperature	Thickness (um)	HV	Application Temperature	Friction coefficient
TiAlN	Purple-Gray	<600°C	3-5	3300	800 °C	0.3
AlTiN	Black	<600 °C	3-5	3500	900 °C	0.3
TiSiN	Copper	<600 °C	3-5	3500	1500 °C	0.4
NaNo	Blue	<600 °C	3-5	3800	1200 °C	0.4
CrN	Silver Gray	<480 °C	2-2.5	2500	700 °C	0.3

4.Packing

Laser print brand name on cutter shank, 1 pcs in a plastic tube, 10 pcs per group

5.Delivery time

Keep stock for regular types
Samples: 3 - 5 days
Regular orders: 7 - 10 days

6.Standard Sizes

Model No.	Flute dia (d)	Cutting length ( l )	Shank dia (D)	Overall length(L)
1.0×2.5×4D×50L	1.0	2.5	4	50
1.5×4×4D×50L	1.5	4	4	50
2.0×5×4D×50L	2.0	5	4	50
2.5×7×4D×50L	2.5	7	4	50
3.0×8×4D×50L	3.0	8	4	50
3.5×10×4D×50L	3.5	10	4	50
4.0×10×4D×50L	4	10	4	50
4.5×11×6D×50L	4.5	11	6	50
5.0×13×6D×50L	5.0	13	6	50
5.5×13×6D×50L	5.5	13	6	50
6.0×15×6D×50L	6.0	15	6	50
6.5×15×8D×60L	6.5	15	8	60
7.0×17×8D×60L	7.0	17	8	60
7.5×17×8D×60L	7.5	17	8	60
8.0×20×8D×60L	8.0	20	8	60
8.5×25×10D×75L	8.5	25	10	75
9.0×25×10D×75L	9.0	25	10	75
9.5×25×10D×75L	9.5	25	10	75
10.0×25×12D×75L	10.0	25	12	75
10.5×25×12D×75L	10.5	25	12	75
11.0×28×12D×75L	11.0	28	12	75
11.5×28×12D×75L	11.5	28	12	75
12.0×30×12D×75L	12.0	30	12	75
13.0×33×16D×100L	13.0	33	16	100
14.0×40×16D×100L	14.0	40	16	100
15.0×40×16D×100L	15.0	40	16	100
16.0×40×16D×100L	16.0	40	16	100
17.0×40×20D×100L	17.0	40	20	100
18.0×40×20D×100L	18.0	40	20	100
19.0×40×20D×100L	19.0	40	20	100
20.0×40×20D×100L	20.0	40	20	100
25.0×40×25D×100L	25.0	40	25	100

7.Our advantages

1.Solid carbide lasting long life in hardened steels, Grain size carbide, high toughness, high-wearing feature.
2.Non-standard can be customized according to customer's requirement
3.We have produce ability to satisfy your orders,another manufacturing bases will be completed in the near month.
4.100% virgin tungsten carbide powder
5.7 years professional experience
6.OEM service

8.Company Information

Zhuzhou Grewin Tungsten Carbide Tools Co., Ltd is located in hometown of Chinese carbide industry - Zhuzhou city. The company has more than 20 years' experience in manufacture, design and sale of various kinds of carbide products, main products include: carbide end mills, carbide rods, indexable inserts, brazed inserts, wire drawing dies, forging dies, wood working tools, saw tips, mining buttons, etc. With excellent quality, strong technical support, and good after sales service, Grewin Carbide brand products are sold to more than 50 countries in the world, such as Europe, USA, south east Asia, middle east, south America, etc.

The company is dedicated to " WE GROW, WE WIN". Grewin Carbide is growing up with the World's carbide technology, to meet the demand of our customers from all over the world.
