60HRC Carbide Button Bits Tungsten Indexable Roughing End Mill Copper Coated
10pcs
MOQ
negotiable
Price
60HRC Carbide Button Bits Tungsten Indexable Roughing End Mill Copper Coated
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: Zhuzhou--Carbide City
Brand Name: Whitout Brand
Certification: ISO9001, SGS
Model Number: As your requirements
High Light:

60HRC Carbide Button Bits

,

Copper Coated Carbide Button Bits

,

Tungsten Indexable Roughing End Mill

Payment & Shipping Terms
Packaging Details: 1PCS in a plastic tube, 10 PCS per group
Delivery Time: 15-25 work days
Payment Terms: T/T, PAYPAL, WESTERN UNION
Supply Ability: 50000pcs/Month
Specifications
Delivery Time: 7-10 Days
Flutes: 1, 2
HRC: 45, 55, 60, 65
Type: Point Driil, Center Drill
Package: 1 PCS In A Plastic Tube, 10 PCS Per Group
Usage: General High Speed Cutting
Coating: Altin, Tiain, Tisin, Ticn, Tin, Tialn, Uncoated
Flute Diameter: 0.5mm-25mm,Customized
Product Description

What is the advantage of our drills?



1. Material: 100% virgin raw material with submicron grain size;
2. Grade: Various grades for choice;
3. Advanced production equipments and testing equipments
4. Precision Ground and polished;
5. High wear resistance,high hardness and impact toughness;
6. Advanced technology , automatic pressing , HIP sintering and precision grinding;
7. Samples & small orders are acceptable

60HRC Carbide Button Bits Tungsten Indexable Roughing End Mill Copper Coated 060HRC Carbide Button Bits Tungsten Indexable Roughing End Mill Copper Coated 1


Super Raw Material

HRC45 HRC55 HRC60 HRC65
Grain Size:0.6um
Co:10 %
Flexural strength:3350N/mm2
Grain Size:0.6um
Co:10 %
Flexural strength:4000N/mm2
Grain Size:0.5um
Co:12 %
Flexural strength:4300N/mm2
Grain Size:0.4um
Co:12.5 %
Flexural strength:4300N/mm2


Coating


Coating

Color

Coating Temperature

Thickness (um)

HV

Application Temperature

Friction coefficient

TiAlN
Purple-Gray <600°C 3-5 3300 800 °C 0.3
AlTiN Black <600 °C 3-5 3500 900 °C 0.3
TiSiN Copper <600 °C 3-5 3500 1500 °C 0.4
NaNo Blue <600 °C 3-5 3800 1200 °C 0.4
CrN Silver Gray <480 °C 2-2.5 2500 700 °C 0.3

Packing
Laser print brand name on cutter shank, 1 pcs in a plastic tube, 10 pcs per group
Delivery time
Keep stock for regular types
Samples: 3 - 5 days
Regular orders: 7 - 10 days
