No Coating Tungsten Carbide Grinding Bit 6mm Carbide Burrs For Steel Aluminium
10pcs
MOQ
No Coating Tungsten Carbide Grinding Bit 6mm Carbide Burrs For Steel Aluminium
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: China
Brand Name: Grewin
High Light:

No Coating Tungsten Carbide Grinding Bit

,

Aluminium Tungsten Carbide Grinding Bit

,

6mm Carbide Burrs For Steel

Payment & Shipping Terms
Packaging Details: plastic box
Delivery Time: 7-10days
Payment Terms: T/T, Western Union, T/T, Western Union
Specifications
Material: Tungsten Carbide
Name: Tungsten Carbide Rotary Burr
Coating: No Coating
Product Description

Carbide Burrs / Tungsten Carbide Rotary Burr Tungsten Carbide Rotary Burrs Grinding Tools Tungaten carbide rotary burr


1.Introduction of carbide burrs

Carbide Rotary Files/Tungsten Carbide Burrs is a new tape milling cutter with high efficiency, instead of grinding wheel bur with handle. It can cut and process various kinds of metal(including hardened steel)and nonmetal(such as marble)with hardness up to HRC less then 70.


2.Details of carbide burrs

Product Name Tungsten Carbide Rotary Burrs
Material Carbide
Tooth Types Single Cut/Double Cut
Sizes Shank dia:3mm,4mm,6mm;blade dia/blade length/overall length: standard/as request
Applications Using Carbide Rotary Burrs is a effective way to realize mechanization in hand works operations. In the industries of airplane, ship building automobile, machinery, chemistry etc. Carbide Rotary Burrs can be widely used in machining iron, steel casting, carbon steel, alloy steel, stainless steel, hardened steel, copper, Aluminium etc.
Advantage high productivity, good processing quality, high finish, can be used to process a variety of high economic efficiency.



COD. A D1 D2 L2 L1
mm mm mm mm
A0207 2.3 6 7 38
300206 2 6 10 55
300306 3 6 14 55
300406 4 6 14 55
300606 6 6 18 65
300806 8 6 18 65
301006 10 6 20 65
301206 12 6 25 65
301606 16 6 25 65
301608 16 8 25 70
302006 20 6 25 70
302008 20 8 25 70
Type. B D1 D2 L2 L1
mm mm mm mm
B0207 2.3 6 7 38
300206-ST 2 6 10 55
300306-ST 3 6 14 55
300406-ST 4 6 14 55
300606-ST 6 6 18 65
300806-ST 8 6 18 65
301006-ST 10 6 20 65
301206-ST 12 6 25 65
301606-ST 16 6 25 65
301608-ST 16 8 25 70
302006-ST 20 6 25 70
302008-ST 20 8 25 70
Type. C D1 D2 L2 L1
mm mm mm mm
C0207 2.3 6 7 38
310206 2 6 10 55
310306 3 6 14 55
310406 4 6 14 55
310606 6 6 18 65
310806 8 6 18 65
311006 10 6 20 65
311206 12 6 25 65
311606 16 6 25 65
311608 16 8 25 70
312006 20 6 25 70
312008 20 8 25 70
Type. D D1 D2 L2 L1
mm mm mm mm
D0201 2 6 1.8 38
D0202 2.3 6 2 38
380206 2 6 1.8 55
380306 3 6 2.7 55
380306-L 3 6 2.7 100
380406 4 6 3 55
380406-L 4 6 3 100
380606 6 6 5 65
380806 8 6 7 65
381006 10 6 9 65
381206 12 6 10 65
381606 16 6 14 65
381608 16 8 15 60
382006 20 6 18 63
382008 20 8 18 63


Specification






No Coating Tungsten Carbide Grinding Bit 6mm Carbide Burrs For Steel Aluminium 0


No Coating Tungsten Carbide Grinding Bit 6mm Carbide Burrs For Steel Aluminium 1

No Coating Tungsten Carbide Grinding Bit 6mm Carbide Burrs For Steel Aluminium 2


Company Introduction

Zhuzhou Grewin Tungsten Carbide Tools Co., Ltd is located in hometown of Chinese carbide industry - Zhuzhou city. The company has more than 20 years' experience in manufacture, design and sale of various kinds of carbide products, main products include: carbide end mills, carbide rods, indexable inserts, brazed inserts, wire drawing dies, forging dies, wood working tools, saw tips, mining buttons, etc

The company has passed ISO 9001: 2008 quality system, possesses advanced production equipments, complete testing instruments, strong R&D center and QC teams.

With excellent quality, strong technical support, and good after sales service, Grewin Carbide brand products are sold to more than 50 countries in the world, such as Europe, USA, south east Asia, middle east, south America, etc.


The company is dedicated to " WE GROW, WE WIN". Grewin Carbide is growing up with the World's carbide technology, to meet the demand of our customers from all over the world.


Any of your inquiry, we are always welcome!
