HRC60 Carbide Square End Mill 4 Flutes Flat CNC End Mill Cutter 8x60mm
10pcs
MOQ
HRC60 Carbide Square End Mill 4 Flutes Flat CNC End Mill Cutter 8x60mm
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: Zhuzhou--Carbide City
Brand Name: Whitout Brand
Certification: ISO9001, SGS
Model Number: As your requirements
High Light:

HRC60 Carbide Square End Mill

,

4 Flutes Carbide Square End Mill

,

8x60mm CNC End Mill Cutter

Payment & Shipping Terms
Packaging Details: 1PCS in a plastic tube, 10 PCS per group
Delivery Time: 15-25 work days
Payment Terms: T/T, PAYPAL, WESTERN UNION
Supply Ability: 50000pcs/Month
Specifications
Model Number: HRC60 Flat End Mill
Processing: Metal
HRC: 60
Machine Type: CNC Milling Machine
RPM: <8000RPM
Material: Carbide
Coating: TiAIN, TiAlN
Flutes: 4
Product Description

HRC60 solid tungsten carbide end mill types of milling cutter for steel manufacturer



  • Are you manufacturer? Do you have factory?

We are not Professional manufacturer, but we have more than 20 years experience with excellent manufacturer cooperation in this field.

  • Will you give me a sample?

You can arrange transportation. We can provide samples.
(3) Do you make label?
Yes, we do. We have laser machine, can laser your logo and sizes on the body of milling cutter, also can print labels.
(4) How about the delivery time?
According to the sizes and quantity, delivery time is different. Usually be 3~5 days. We can tell you exact inventory state if you need.
(5) Can you produce carbide Special Tool ?
Yes We can. We can special tool according your drawing and sample.





Product Name HRC60 solid tungsten carbide flat end mill 8*20*60*8D*4F
Features Variable helix angle and unequal flute spacing
Processing Type Metal
Precision within 0 ~-0.01mm
HRC 60
Suitable For Stainless Steel, Alloy steel, Die steel, Pre-hardened Steel, Inconel
Machine Type CNC Milling Machine
Flutes 4
Specification 8*20*60*8D*4F
Co 12%
TRS Min(N/MM²) 4200
HRA 92.2-93



Standard Sizes:

Order No. Flute dia (d) Cutting length ( l ) Shank dia (D) Overall length(L)
1.0×2.5×4D×50L 1.0 2.5 4 50
1.5×4×4D×50L 1.5 4 4 50
2.0×5×4D×50L 2.0 5 4 50
2.5×7×4D×50L 2.5 7 4 50
3.0×8×4D×50L 3.0 8 4 50
3.5×10×4D×50L 3.5 10 4 50
4.0×10×4D×50L 4 10 4 50
4.5×11×6D×50L 4.5 11 6 50
5.0×13×6D×50L 5.0 13 6 50
5.5×13×6D×50L 5.5 13 6 50
6.0×15×6D×50L 6.0 15 6 50
6.5×15×8D×60L 6.5 15 8 60
7.0×17×8D×60L 7.0 17 8 60
7.5×17×8D×60L 7.5 17 8 60
8.0×20×8D×60L 8.0 20 8 60
8.5×25×10D×75L 8.5 25 10 75
9.0×25×10D×75L 9.0 25 10 75
9.5×25×10D×75L 9.5 25 10 75
10.0×25×12D×75L 10.0 25 12 75
10.5×25×12D×75L 10.5 25 12 75
11.0×28×12D×75L 11.0 28 12 75
11.5×28×12D×75L 11.5 28 12 75
12.0×30×12D×75L 12.0 30 12 75
13.0×33×16D×100L 13.0 33 16 100
14.0×40×16D×100L 14.0 40 16 100
15.0×40×16D×100L 15.0 40 16 100
16.0×40×16D×100L 16.0 40 16 100
17.0×40×20D×100L 17.0 40 20 100
18.0×40×20D×100L 18.0 40 20 100
19.0×40×20D×100L 19.0 40 20 100
20.0×40×20D×100L 20.0 40 20 100
25.0×40×25D×100L 25.0 40 25 100

1.Super Coating





2.Advanced Equipment

  • ANCA & for producing end mills
  • PG1000 & PARLEC for detecting



3.Wide Application

HRC50 suitable for Iron, Cast Iron, Common Steel under hardness HRC45

HRC55 suitable for Iron, Cast Iron, Common Steel, Hardened Steel under hardness HRC55

HRC60 suitable for Pre-hardened steel; Stainless steel; Alloy steel; Die steel under HRC60

HRC65 suitable for Hardened steel; Mold steel; Die steel; Alloy steel above HRC60



HRC60 Carbide Square End Mill 4 Flutes Flat CNC End Mill Cutter 8x60mm 0

HRC60 Carbide Square End Mill 4 Flutes Flat CNC End Mill Cutter 8x60mm 1

We are waiting for your inquiry!
